PRODUCT DETAILS:
- Pack Type: Box
- Pack Quantity: 100 Pieces
- Barcode: 5055017529995
RAPID & EFFECTIVE FIXING SOLUTION:
- Ideal for light-duty anchoring in concrete, brick, stone, concrete block, and wood.
- Replaces traditional fixings like nylon frame and hammer fixings with a versatile through fixing solution.
KEY FEATURES:
- Designed to replace traditional masonry fixings, offering a modern alternative.
- TX30 TX Drive recess reduces driver wear and prevents camming-out.
- Serrated V-threads for optimal insertion into various masonry types.
- Zinc-plated and yellow passivated for enhanced corrosion resistance.
- High-Low thread on the first 30mm aids insertion and reduces torque.
- Perfect for securing windows and door frames.
- Features a flat countersunk head with five locking ribs.
- Complies with BS 7671 standard's 18th edition, ensuring non-flammability and support for wiring systems in fire events.
PRODUCT SPECIFICATIONS:
- Approval: BS 7671:2018
- Brand: TIMCO
- Corrosion Rating (1-5): 1 - Suitable for clean, dry, and low humidity environments
- Driver Bit Size: TX30
- Feature 7: Flat countersunk head with five locking ribs
- Feature 8: All-steel, non-flammable fixing conforming to BS 7671 standard's 18th edition
- Finish: Zinc & Yellow
- Fixture Hole Size Ø (mm): 8
- Head Type: Flat Countersunk with Ribs
- Included Items: TX30 S2 Bit (Qty 1)
- Material: Carbon Steel
- MFT (mm): 15
- Minimum Order Quantity (MOQ): 1
- MOQ Increment: 1
- Pack Dimensions (L x W x H mm): 122 x 82 x 74
- Pack Qty: 100
- Pack Weight (kg): 0.9
- Packs per Carton: 12
- Packs per Pallet: 432
- Point Type: Sharp
- Recess Type: TX Drive
- Size Ø x L (mm): 7.5 x 50
- Substrates: Wood, Concrete, Brick, Block, Stone
- Thread Coverage: Fully Threaded
- Thread Diameter (mm): 7.5
- Thread Type: High-Low Start with V Flutes
Elevate your anchoring projects with Concrete Screws - TX - Flat Countersunk - Yellow (7.5 x 50). These versatile screws offer a rapid and effective solution for light-duty anchoring in various materials. Designed to replace traditional masonry fixings, they provide a modern alternative with features like TX Drive recess, serrated V-threads, and enhanced corrosion resistance. Whether you're securing windows, door frames, or working with wood, concrete, brick, block, or stone, these screws ensure reliable and safe fastening. Complying with BS 7671 standard's 18th edition, they guarantee non-flammability, making them a dependable choice for wiring systems in fire events.
